Dew point measurement range: -80...20 °Ctd BM146; -60...20 °Ctd BM147
Pressure measurement range: absolute pressure 1...17 bar
Temperature measurement range: -40...+100°C range can be customized
Dew point accuracy: +/- 2 °Ctd (air or nitrogen)
Temperature accuracy: -80 -> -30 °Ctd 20s [40s]
0...+50°C : +/-0.3°C (Standard)
-40...0°C and +50...+100 °C : +/-0.5°C (Standard) Temperature Accuracy can be customized.
Pressure accuracy: 23°C+/-0.3 %FS pressure drift with temperature+/-0.01 bar/10°C
Response time: 63% [90%],20°C,1bar(gauge),4L/min
Dew point sensor: -80 -> -30 °Ctd 20s [40s]; -30 -> -70 °Ctd 5min[20min]
Pressure response time: <1 s
Current output: 4...20 mA(3 lines) range can be changed
Current output resolution: 0.002 mA
Temperature drift of current output: 0.01% of span/°C
Current output load: Maximum 500Ω
Digital output: RS485
Connector: 5-pin M12
Automatic heating: 16...30 V/250 mA
Normal measurement: 16...30V/30 mA + 4-20mAcurrent output
Working temperature: -20...+70 °C
Storage temperature: -30...+80 °C
Relative humidity: 0...95 %RH
Sample flow rate: >1 L/min
Pressure: 0...50 bar
Protection level: IP65
Mechanical parts connection: ISO G 1/2”
Stainless steel mesh filter: filter grade<30um<30um
EMC: IEC 61326-1
