IR resolution: Focal plane array (FPA), uncooled microbolometer: 120x90
Field of View (FOV): 50°x38°
Spatial resolution: (IFOV): 2.74mrad
Thermal sensitivity/NETD: < 0.05°C @ +30°C/(+86oF), < 0.1°C/100mK
Image frequency: 9Hz
Focus: Focus free
Image presentation
Display: 3.5" 640x480 touch screen
Image modes: IR image, visual image, picture in picture, AUF
Color palettes: IRON, Rainbow, Grey, Grey Inverted, Brown, Blue-red, hot-cold, Feather
Measurement
Object temperature range: -20°C-330°C (-4°F-302°F)
Accuracy: ±5°C (±3.6°F)/±3% of reading
Measurement analysis
Emissivity adjustable: 0.01~1.0 Adjustable
Automatic hot /cold detection: Auto hot or cold spotmeter marks
Set-up
Laser / floodlight: <class2/while LED floodlight
Language selection: English, Chinese, French, German, Spanish, Japanese, Korean, Portuguese, Italian
Storage of videos/images
Storage media: 4Gbytes eMMC or 8GB SD card
Video storage format: Standard MPEG-4, 640x480@30fps, on memory card > 60 minutes
Image storage format: Standard JPEG, including measurement data, on memory card > 1000 pictures
Storage mode: IR/visual images; simultaneous storage of IR and visual images
Digital camera
Built-in visible light digital camera: 2M Pixels
Data communication interfaces
USB interfaces:
USB-micro, data transform between camera and PC
Remote control, live video
Wi-Fi connectivity: Wi-Fi connectivity allows to send images and data to mobile devices remote control, live video
Power system
Battery: Lithium polymer battery, 4 hours operating time
Input voltage: DC 5V
Charging system: In camera (AC adapter)
Power management: Automatic shutdown and sleep mode (user selectable)
Size (HxWxD): 228mm x 100mm x 90mm Weight: 520g
Accessories:
Hard transport case, 7.5mm lens, Tripod base, AC charger/Power supply, Battery, software CD-ROM, Handstrap, micro SD card, USB cable, Gift box
