CEM DT-891 Industrial Thermal Imagers (-20°C-450°C,240x320px)

Imaging and Optical Data

Field of View: 21x21

Spatial Resolution: 4.53mrad

NETD: <0.1°C@30°C(80°F)/100mK

Image Frequency: 25Hz

Focus Mode: Focus free

Focal Plane Array(FPA)/Spectral Range: Uncooled microbolometer/8-14um

IR Resolution: 120x90

Image Presentation

Display: 2" TFT LCD, 240x320 pixels

Color Palettes: IRON

Measurement

Object Temperature Range: -20°C-450°C (-4°F-842°F)

Accuracy: ±2°C(±3.6°F)/ ±2% of reading

Measurement Analysis

Spotmeter: Center Spot

Automatic Hot/Cold Detection: Auto hot or cold markers

Emissivity Correction: 8 pre-define level and Variable from 0.01-1.0-

Storage of Images

Storage Media: 8 Gbytes Micro SD card

Image Storage format: Bitmap(BMP),including measurement data.

Data Communication Interfaces

Interfaces: USB-micro, Data transform between camera and PC

Bluetooth

Power System

Battery: Li-ion battery, 8 hours operting time

Input Voltage: DC 5V

Charging System: In camera(AC adapter)

Power Management: Automatic shutdown

Environmental Data

Operating Temperature Range: -20°C-50°C (-4°F-122°F)

Storage Temperature Range: -40°C-70°C (-40°F-158°F)

Humidity(operating and storage): 10%-90%

Drop test: 2m

Size(HxWxD):180mm x 58mm x 70mm

Weight:480g

Accessories:

Battery, software CD-ROM, Wrist strap, micro SD card, Adaptor, USB cable, Gift box.
