CEM DT-61 6 in 1 Digital Multimeter with Environment Measurement (600V,10A)

Function - Max. Range - Max.Resolution - Basic Accuracy

Light

20,000Lux ; 0.1Lux ; 0.5%±10d

40,000Lux ; 0.1Lux ; 0.5%±10d

Sound: 100dB ; 0,1dB ; ±3.5dB

Humidity: 99%RH ; 0.1%RH ; ±3.5%RH

Temperature

﹣20 ～750℃ ; 0.1°up to 400°，1°over 400° ; ±3%±3℃

﹣4～1400℉ ; 0.1°up to 400°，1°over 400° ; ±3%±5℉

NCV: 50～1000V  

Voltage DC: 600V ; 0.1mV ; ±0.5%±2d

Voltage AC: 600V ; 0.1mV ; ±1.2%±10d

Current DC: 10A0.1uA ; ±1.0%±2d

Current AC: 10A0.1uA ; ±1.0%±2d

Resistance: 40MΩ ; 0.1Ω ; ±0.8%±2d

Capacitance: 100uF ; 0.01nF ; ±3.5%

Frequency: 10MHz ; 0.001Hz ; ±1.5%

Duty Cycle: 99.9% ; 0.1% ; ±1.2%

Diode Check: Open voltage 2.8VDC; Test current 1mA

Continuity TestThreshold 30Ω

Accessories

9V battery, Test leads and K-Type temperature probe. Infrared Temperature Probe (Option IR-82)
