CEM DT-5530 Insulation Testers (AC-750V, DC-1000V, 2000MΩ)

Function: Range - Max Resolution - Basic accuracy

Voltage AC: 750V ; 1V ; ±1.2%rdg ±10dgts

Voltage DC: 1000V ; 1V ; ±0.8%rdg ±3dgts

Resistance: 20MΩ, 200Ω, 2000Ω0.1Ω, 1Ω±1%rdg ±2dgts

Insulation Resistance: 200MΩ, 2000MΩ ; 100kΩ~1MΩ 10kΩ ; ±3.5%rdg ±5dgts

Test Voltage: 250V-200MΩ/500V-200MΩ/1000V-2000MΩ/500V-20MΩ

Continuity Test: Active Sound Level: ≤40Ω, Test current ≤200mA

Operating Temp: 0ºC~40ºC (<80%R.H.)

Storage Temp: -10ºC~60ºC (<70%R.H.)

Power Source: 1.5V “AA” size Battery x 6

Size(HxWxD): 200mm x 92mm x 50mm

Weight: 582g

Accessories

Test leads, “AA” Battery x 6 and gift box with carrying case.
