CEM DT-382 AC/DC Autoranging Clamp Meters (AC/DC 200A)

Voltage DC (Max Range; Basic Accuracy): 600V; ±(0.5%+1d)

Voltage AC (Max Range; Basic Accuracy): 600V; ±(1.5%+2d)

Current DC (Max Range; Basic Accuracy): 200A; ±(2.0%+5d)

Current AC (Max Range; Basic Accuracy): 200A; ±(2.5%+4d)

Resistance (Max Range; Basic Accuracy): 20MΩ; ±(3.0%+5d)

Temperature (Max Range; Basic Accuracy): 1000°C/ 1832°F; ±(3.0%+3d)

Continuity check: Buzzer sounds at 50Ω

Diode test: Test current 0.3mA

Size (HxWxD): 230mm x 82mm x 40mm

Weight: 230g

Accessories: Test leads, gift box with carrying case, temperature probe and Two“AAA”1.5V batteries.
