Function: Max Range - Basic Accuracy
Voltage DC: 600V ; ±(0.5%+1d)
Voltage AC: 600V ; ±(1.5%+2d)
Current DC: 400A ; ±(2.0%+5d)
Current AC: 400A ; ±(2.5%+4d)
Resistance: 40MΩ ; ±(3.0%+5d)
Temperature: 760ºC/ 1400ºF ; ±(3.0%+3d)
Capacitance: 100uF ; ±(2.5%+5d)
Frequency: 10kHz ; ±(1.2%+2d)
Continuity check: Buzzer sounds at 50Ω
Diode test: Test current 0.3mA
Size (H x W x D): 198mm x 66mm x 36mm
Weight: 230g
Accessories: Test leads, gift box with carrying case, Temperature probe and Two“AAA”1.5V batteries.
Datasheet
Features | DT-350 | DT-351 | DT-352 | DT-353 |
Current measurement | AC | AC/DC | AC | AC/DC |
LCD display counts | 4000 | 4000 | 2000 | 50000 |
Data Hold | * | * | * | * |
REL (Zero) Function | * | * |
| * |
Auto Power Off | * | * | * | * |
Low battery indication | * | * | * | * |
1.2” (30mm) Jaw opening | * | * | * | * |
NCV Detection | * | * | * | * |
Specifications | ||||||
Function | Max Range | Basic Accuracy | DT-350 | DT-351 | DT-352 | DT-353 |
Voltage DC | 600V | ±(0.5%+1d) | * | * | * | * |
Voltage AC | 600V | ±(1.5%+2d) | * | * | * | * |
Current DC | 400A | ±(2.0%+5d) |
| * |
| * |
Current AC | 400A | ±(2.5%+4d) | * | * | * | * |
Resistance | 40MΩ | ±(3.0%+5d) | * | * | * | * |
Temperature | 760ºC/ 1400ºF | ±(3.0%+3d) | * | * | * | * |
Capacitance | 100uF | ±(2.5%+5d) | * | * |
| 10mF |
Frequency | 10MHz | ±(1.2%+2d) | * | 10kHz |
| * |
Continuity check | Buzzer sounds at 50Ω | |||||
Diode test | Test current 0.3mA | |||||
