CEM DT-3368 AC/DC Clamp Meters (AC/DC-1000A/600V True RMS)

ManufacturerCEM

ModelDT-3368

OriginChina

Warranty12 months

USD 103.07

Quantity

Secure Checkout

Quality Engagement

Easy change and return

Delivery Available

Function: Max. Range - Basic Accuracy - Max. Resolution

Current DC: 1000A ; ±(2.5%+5d) ; 1mA

Current AC: 1000A ; ±(3.0%+4d) ; 10mA

Voltage DC: 600V ; ±(0.8%+2d) ; 0.1mV

Voltage AC: 600V ; ±(1.0%+4d) ; 0.1mV

Resistance: 66MΩ ; ±(1.0%+4d) ; 0.1Ω

Capacitance: 40mF ; ±(3.0%+5d) ; 0.01nF

Frequency: 10kHz ; ±(1.2%+3d) ; 0.001Hz

Duty Cycle: 99.90% ; ±(1.2%+3d) ; 0.10%

Temperature: 1000ºC/1832ºF ; ±(3.0%+3d) ; 0.1ºC/ºF

Inrush Current: 1000A ; 0.1A ; ±(2.0%+5d)

Continuity check: Threshold 40Ω, test current <0.5mA

Diode test: Test current of 0.3mA typical, open circuit voltage <3V DC typical

Size (H x W x D): 229mm x 80mm x 49mm

Weight: 303g

Accessories: Test leads, gift box with carrying case, 9V battery, Temperature probe (3361/3363/3367/3366/3368)

Datasheet

Features	DT-3360	DT-3361	DT-3363	DT-3367	DT-3368
Digital display counts	6000	6000	6000	6000	6600
Analog Bargraph/Segments	*/60	*/60	*/60	*/60	*/60
Electronic overload protection	*	*	*	*	*
Continuity buzzer & Diode check	*	*	*	*	*
Data Hold function	*	*	*	*	*
DCA Zero function			*	*	*
Min/Max Hold function	*	*	*	*	*
Auto Power Off	*	*	*	*	*
Low battery indication	*	*	*	*	*
AC/DC Current	AC current	AC current	*	*	*
True RMS measurements				*	*
1.2” (30mm) Clamp jaw opening	*	*	*	*
Inrush current function					*

Function	Max. Range	Basic Accuracy	Max. Resolution	DT-3360	DT-3361	DT-3363	DT-3367	DT-3368
Current DC	1000A	±(2.5%+5d)	1mA			*	*	*
Current AC	1000A	±(3.0%+4d)	10mA	*	*	*	*	*
Voltage DC	600V	±(0.8%+2d)	0.1mV	*	*	*	*	*
Voltage AC	600V	±(1.0%+4d)	0.1mV	*	*	*	*	*
Resistance	60MΩ	±(1.0%+4d)	0.1Ω	*	*	*	*	66MΩ
Capacitance	4000µF	±(3.0%+5d)	0.01nF	*	*	*	*	40mF
Frequency	10MHz	±(1.2%+3d)	0.001Hz	*	*	*	*	10kHz
Duty Cycle	99.90%	±(1.2%+3d)	0.10%	*	*	*	*	*
Temperature	1000ºC/1832ºF	±(3.0%+3d)	0.1ºC/ºF		*	*	*	*
Inrush Current	1000A	0.1A	±(2.0%+5d)					*
Continuity check	Threshold 40Ω, test current <0.5mA
Diode test	Test current of 0.3mA typical, open circuit voltage <3V DC typical
