Function: Max Range - Max. Resolution - Basic Accuracy
AC True RMS Current
60.00A ; 100mA ; ±(2.5%+8d)
1000A ; 1A ; ±(3%+8d)
DC Current
60.00A ; 100mA ; ±(2.5%+0.2A)
1000A ; 1A ; ±(3%+8d)
DC Voltage: 600.0mV, 6000V,60.00V,600.0V,1000V ; 0.1mV ; ±(0.8%+20d)
AC True RMS Voltage: 6.000V,60.00V,600.0V,1000V ; 1mV ; ±(1.0%+5d)
Resistance: 600.0Ω,6.000kΩ,60.00kΩ,600.0kΩ,6.000MΩ,60.00MΩ ; 0.1Ω ; ±(1%+4d)
Capacitance: 6.000nF,60.00nF,600.0nF,6.000uF,60.00uF,600.0uF,6.000uF ; 1pF ; ±(5%+30d)
Frequency: 6.000Hz,60.00Hz,600.0Hz,6.000KHz,60.00KHz,600.0KHz,10MHz ; 0.001Hz ; ±(1.0%+5d)
Frequency: 10Hz to 10kHz,40Hz to 100Hz ; ; ±(1.0%+5d)
Duty cycle: 0.5%~99.9% ; 0.1 ; ±(1.2%+10d)
Temperature: ﹣50℃~﹢1000℃,﹣58℉~﹢1832℉ ; 0.1℃/℉ ; ±(3%+5℃/9℉)
Total Harmonic Distortion: 99.9% ; 0.1% ; ±(3%+10d)
Harmonic Distortion measurement: 99.9% ; 0.1% ; ±(5%+10d)
Active Power: 999.9KW ; ; A.error x v.reading+V.error x A.reading
Power Factor: ﹣1.0~0,0~1.0 ; ; ±(3%+1d)
Diode test: Forward DCA is approx.1mA, open circuit Voltage MAX, 3V
Continuity check: Buzzer sounds at 50Ω
Size(HxWxD): 230mm x 76mm x 40mm
Weight: 315g
Accessories: Test leads, temperature probe, gift box with carrying case, 9V battery
Datasheet
Features |
True RMS |
Non-contact voltage detection |
Inrush current measurement for motors |
Low pass filter for variable frequency drives |
Continuity Beeper |
Min, Max and Smart Data Hold, Peak hold |
Auto torch-light when clamping |
Linterna automática durante el apriete |
Large 10,000 count display with active backlight and analog bar graph |
Auto Power Off |
Maximum jaw opening 1.63” (42mm) |
CAT IV 600 V /CAT III 1000 V safety standard |
Bluetooth interface |
Meterbox iMM & cloud service |
