Imaging and optical data
Field of view (FOV) / Minimum focus distance: 24.6°x 18.6°/ 0.5m
Spatial resolution (IFOV): 1.14mrad
Thermal sensitivity/NETD: <0.05oC/50mK
Image frequency: 50Hz
Focus mode: Manual
Focal length: 22mm
Focal Plane Array(FPA)/Spectral range: Uncooled microbolometer/8-14 µm
IR resolution: 384x288
Image presentation
Image modes: IR image only
Color palettes: IRON, Rainbow, Grey, Grey Inverted, Sepia, Blue_Red, Hot_Cold, Humidity
Measurement
Object temperature range: –20°C to +150°C (–4°F to +302°F), 0°C to +400°C (+32°F to +752°F)
Accuracy: ±2°C (±3.6°F) or ±2% of reading
Data communication interfaces
Interfaces: USB, composite video
USB: Remote control
Video out: Composite (PAL and NTSC)
Ethernet type, connector type，video streaming
Alarm output: 2 relay output
Power system
Input voltage: DC 9V to 12V
Options Lens
11mm: 7.1°x 36.2°
38mm: 14.4°x 10.8°
Size (HxWxD): 130mm x 60mm x 74mm
Weight: 1000g
Accessories:
Infrared camera with lens, CVBS cable, RS485 cable, Network cable, Gift box.
