Voltage DC (Maximum; Max resolution; Accuracy): 1000V; 0.1mV; ±(0.9% + 5d)
Voltage AC (Maximum; Max resolution; Accuracy): 1000V; 0.1mV; ±(1.5% + 5d)
Current DC (Maximum; Max resolution; Accuracy): 10A; 0.1μA; ±(1.5% + 3d)
Current AC (Maximum; Max resolution; Accuracy): 10A; 0.1μA; ±(1.8% + 5d)
Temperature (Maximum; Max resolution; Accuracy):
-40°C-1000°C;0.1°C/1°C;±(3.0%)
-40°F-1832°F;0.1°F/1°F;±(3.0%)
Resistance (Maximum; Max resolution; Accuracy): 60MΩ; 0.1Ω; ±(1.0% + 2d)
Capacitance (Maximum; Max resolution; Accuracy): 60mF; 0.01nF; ±(4.0% + 5d)
Frequency (Maximum; Max resolution; Accuracy): 10MHz; 0.01Hz; ±(1.0% + 5d)
RPM (Tach) (Maximum; Max resolution; Accuracy):
600 ~ 4000RPM; ±(2.5%+4d)
600 ~ 12000RPM(x 10RPM); ±(2.5%+4d)
Dwell Angle (Maximum; Accuracy): 4CYL, 5CYL,6CYL, 8CYL; ±(2.5%+4d)
Duty Cycle (Maximum; Accuracy): 0.1~99.9%; ±(2.0%+5d)
Period (Maximum; Accuracy): 60mS; ±(3.0%+5d)
Pulse Width (Maximum; Accuracy): 30mS; ±(3.0%+5d)
Diode and Continuity: Yes
Bluetooth: 4.0
TFT color LCD display
Size (HxWxD): 220mm x 96mm x 60mm
Weight: 631g
Accessories:
Test leads, 6x1.5V AA batteries, Type K temperature probe, Software, gift box with carrying case.
