Load cell excitation voltage: DC 5V
Load cell connection: 10 EA (350Ω)
Load cell input range: -2.0 mV/V~3.0 mV/V
Input Sensitivity: 0.5 ㎶/D (Approval), 0.3 ㎶/D (NonApproval)
A/D Internal resolution: 1/520,000
A/D Display resolution: 1/10,000 (OIML /NTEP/KS), 1/20,000 (Non approval)
A/D Conversion speed: 200 time/sec
A/D conversion method: Sigma-delta
Display: 4.3" TFT Color LCD
Key: Numeric Key 10, Function Key 9
Interface
Standard: RS232 (COM1, COM2)
Option: RS422, RS485, Analog_out /BCD_out
External I/O: -
Power AC: AC 100 ~240V 50/60Hz
Operating Temp: -10˚C ~40˚C
Approval: OIML, CE
Dimensions (W x D x H) mm: 192.9 x 190.2 x 98.4
Weight (kg): 1.5
