Carlo Gavazzi SPD24601B Switching Supplies Switching Power Supply, AC/DC, 60W, 24V, Spring Terminals, IP20, DIN-Rail Mounting, Over-load, Over-voltage and Short-circuit Protections, 40.5x90x114mm housing

Width: 40.5 mm (1.594 in)

Height: 114 mm (4.488 in)

Length: 90 mm (3.543 in)

Industry: Industrial

IP Rating: IP20

Dimensions: 90 mm x 40.5 mm x 114 mm

Input Type: 1-Phase / Single Phase

Unit Weight: 538.640 g

Output Power: 60 W

Input Voltage: 100 VAC to 240 VAC

Mounting Style: DIN Rail Mount

Isolation Voltage: 3 kV

Number of Outputs: 1 Output

Open Frame/Enclosed: Enclosed

Output Current-Channel 1: 2.5 A

Output Voltage-Channel 1: 24 VDC

Maximum Operating Temperature: + 71 C

Minimum Operating Temperature: - 40 C
