Carlo Gavazzi SPD241203 Switching Supplies Switching Power Supply, AC/DC, 120W 3-Phases, 24V, Screw Terminals, IP20, DIN-Rail Mounting, Over-load, Over-voltage and Short-circuit Protections, 74.3x124x118.8mm plastic housing

Width: 64 mm (2.52 in)

Height: 126 mm (4.961 in)

Length: 124.5 mm (4.902 in)

Industry: Industrial

Dimensions: 124.5 mm x 64 mm x 126 mm

Input Type: 3-Phase / Three Phase

Output Power: 120 W

Input Voltage: 90 VAC to 264 VAC

Mounting Style: DIN Rail Mount

Isolation Voltage: 3 kV

Number of Outputs: 1 Output

Open Frame/Enclosed: Enclosed

Output Current-Channel 1: 5 A

Output Voltage-Channel 1: 24 VDC

Maximum Operating Temperature: + 71 C

Minimum Operating Temperature: - 35 C
