Carlo Gavazzi SPD12181 Switching Supplies Switching Power Supply, AC/DC, 18W, 12V, Screw Terminals, IP20, DIN-Rail Mounting, Over-load, Over-voltage and Short-circuit Protections, 22.5x90x114mm housing

Width: 22.5 mm (0.886 in)

Height: 114 mm (4.488 in)

Length: 90 mm (3.543 in)

Industry: Industrial

IP Rating: IP20

Dimensions: 90 mm x 22.5 mm x 114 mm

Input Type: 1-Phase / Single Phase

Unit Weight: 280 g

Output Power: 18 W

Input Voltage: 90 VAC to 264 VAC

Mounting Style: DIN Rail Mount

Isolation Voltage: 3 kV

Number of Outputs: 1 Output

Open Frame/Enclosed: Enclosed

Output Current-Channel 1: 1.5 A

Output Voltage-Channel 1: 12 VDC

Maximum Operating Temperature: + 71 C

Minimum Operating Temperature: - 20 C
