Carlo Gavazzi SPD121002 Switching Supplies Switching Power Supply, AC/DC, 100W Bi-Phase, 12V, Screw Terminals, IP20, DIN-Rail Mounting, Over-load, Over-voltage and Short-circuit Protections, 54x90x114mm plastic housing

Width: 54 mm (2.126 in)

Height: 114 mm (4.488 in)

Length: 90 mm (3.543 in)

Industry: Industrial

Dimensions: 90 mm x 54 mm x 114 mm

Input Type: 2-Phase / Two Phase

Output Power: 100.8 W

Input Voltage: 90 VAC to 264 VAC

Mounting Style: DIN Rail Mount

Isolation Voltage: 500 V

Number of Outputs: 1 Output

Open Frame/Enclosed: Enclosed

Output Current-Channel 1: 8.4 A

Output Voltage-Channel 1: 12 VDC

Maximum Operating Temperature: + 71 C

Minimum Operating Temperature: - 35 C
