Carlo Gavazzi ICS30L50N22NOM1E1 Proximity Sensors Inductive proximity sensor, M30 Stainless steel, M12-plug, Sn 22mm, Non-flush mount, NPN NO output, 8-60Vdc, 200 mA, Max op. freq. 0.3 kHz, Op. temperature -40C to +85C, IP67-IP68-IP69K, 200 V/m Radiated Noise Immunity, Load Dump Protection, E1-type

Length: 87.2 mm

Barrel Size: M30

Mounting Style: Plug

Sensing Method: Inductive

Sensing Distance: 22 mm

Maximum Frequency: 300 Hz

Description/Function: Non-Flush

Output Configuration: NPN-NO

Supply Voltage - Max: 60 VDC

Supply Voltage - Min: 8 VDC

Operating Supply Current: 10 mA

Operating Supply Voltage: 8 VDC to 60 VDC

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 40 C
