Life: 100000 Cycle
Width: 12.83 mm
Height: 27.4 mm
Length: 49.09 mm
Actuator: Convex Rocker
IP Rating: IP66, IP68
Lamp Type: LED
Illuminated: Illuminated
Contact Form: DPDT
Panel Cutout: 36.83 mm x 21.08 mm
Mounting Type: Snap In
Terminal Seal: Sealed
Actuator Style: Convex Rocker
Current Rating: 15 A
Mounting Style: Panel Mount
Actuator Length: 49.09 mm
Contact Plating: Silver
Switch Function: ON - NONE - ON
Housing Material: Polycarbonate (PC)
Actuator Material: Thermoplastic Polycarbonate
Termination Style: Quick Connect
Voltage Rating DC: 24 VDC
Illumination Color: Green
LED Supply Voltage: 24 VDC
Flammability Rating: UL 94 V-0
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
