Life: 250000 Cycles
Color: Black
Width: 25.91 mm
Height: 36.83 mm
Length: 50.04 mm
Actuator: Paddle
Material: Nylon
IP Rating: IP67
Illuminated: Non-Illuminated
Contact Form: DPDT
Panel Cutout: 44.04 mm x 22.02 mm
Mounting Type: Snap In
Terminal Seal: Sealed
Actuator Style: Paddle
Current Rating: 15 A
Mounting Style: Panel Mount
Contact Plating: Gold
Panel Thickness: 3.96 mm
Switch Function: (ON) - OFF - (ON)
Housing Material: Nylon
Actuator Material: Thermoplastic
Termination Style: Quick Connect
Voltage Rating DC: 12 VDC
Flammability Rating: UL 94 V-0
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
