Technical Properties
Measuring Capability: Color, Gloss, Fluroescence, Jetness
Color Measurement
Color Geometry: 45°c:0°
Sample Port: 12 mm
Measuring Area: 08 mm
Spectral Range Colorimetric: 400 - 700 nm, 10 nm resolution
Spectral Range Fluorescence: 340 - 760 nm, 10 nm resolution
Measurement Range: 0 - 170% reflection
Repeatability Color: 0.01 ΔE94 (10 consecutive measurements on white)
Reproducibility Color: 0.1 ΔE94 (average of 12 BCRA II tiles)
Color Systems: CIELab/Ch, Lab(h), XYZ, Yxy
Color Differences: ΔE*; ΔE(h); ΔECMC; ΔE94; ΔE99; ΔE2000; E2000 PF; ΔE DIN6175-2019
Color Indices: YIE313, YID1925, WIE313, CIE, Berger, Color Strength, Opacity, Metamerism, Grayscale
Illuminants: A, C, D50, D55, D65, D75, F2, F6, F7, F8, F10, F11, UL30, CIE 015:2018 LED Illuminants
Observer: 2°, 10°
Fluorescent Indices: ΔE Fl, ΔEzero
Jetness Indices: MY, Mc, dM, GY, Gc, dG
Repeatability Jetness: Y ≤ ± 0.0005
Reproducibility Jetness: Y ≤ ± 0.003 (Y<0.5)
Gloss Measurement:
Repeatability Gloss 0-20: ± 0.1 GU
Repeatability Gloss 20-100: ± 0.2 GU
Reproducibility Gloss 0-20: ± 0.5 GU
Reproducibility Gloss 20-100: ± 1.0 GU
Gloss Geometry: 60°
Gloss Aperture: 5 x 10 mm
Measurement Range Gloss: 0 - 100 GU
General
Memory: 4.000 Standards and 10.000 Samples
Interface: USB port
Display: 3.5 " Color Touchscreen
Languages: English, German, French, Italian, Spanish, Russian, Japanese, Chinese
Power supply: Internal rechargeable battery
Power supply: 100 - 240 V, 50/60 Hz
Battery: 7.2 V, 2350 mAh, 16.92 Wh
Battery Capacity: 1200 readings
Weight: 0.7 kg
Weight: 1.5 lb
Operating temperature: 10 - 40 °C
Storing temperature: 0 - 60 °C
Operating temperature: 50 - 104 °F
Storing temperature: 32 - 140 °F
Relative humidity: Up to 85 % non-condensing at 35 °C (95 °F)
Dimensions: L x W x H: 8.7 x 11 x 18.8 cm
Dimensions: L x W x H: 3.4 x 4.3 x 7.4 in
