Technical Properties:
Measuring Capability: Color, Gloss, Fluorescence, Jetness
- Color Measurement:
Color Geometry: 45°c:0°
Sample Port: 32 mm, 12 mm, 04 mm
Measuring Area: 22 mm, 08 mm, 04 mm
Spectral Range Colorimetric: 400 - 700 nm, 10 nm resolution
Spectral Range Fluorescence: 300 - 760 nm, 10 nm resolution
Measurement Range: 0 - 170% remission
Repeatability Color: 0.01 ΔE94 (10 readings on white)
Reproducibility Color: 0.1 ΔE94 (average of 12 BCRA II tiles)
Color Systems: CIELab/Ch, Lab (h), XYZ, Yxy
Color Indices: YIE313, YID1925, WIE313, CIE, Berger, Color Strength, Opacity, Metamerism, Grayscale
Illuminants: A, C, D50, D55, D65, D75, F2, F6, F7, F8, F10, F11, UL30, CIE 015:2018 LED Normlicht
Observer: 2°, 10°
Jetness Indices: MY, Mc, dM, GY, Gc, dG
Repeatability Jetness: Y ≤ ± 0.0005
Reproducibility Jetness: Y ≤ ± 0.003 (Y<0.5)
- Gloss Measurement:
+) Gloss Measurement: 20°
Measurement Range: 0 - 100 GU
Aperture Size: 9 x 10 mm
Repeatability: 0 - 100 GU: ± 0.2 GU
Reproducibility: 0 - 100 GU: ± 1.0 GU
Available for Aperture: 32 mm, 12 mm
+)Gloss Measurement: 60°
Measurement Range: 0 - 100 GU
Aperture Size: 9 x 16 mm
Repeatability:
0 - 20 GU: ± 0.1 GU
20 - 100 GU: ± 0.2 GU
Reproducibility:
0 - 20 GU: ± 0.5 GU
20 - 100 GU: ± 1.0 GU
Available for Aperture: 32 mm
- General:
Memory: 4,000 standards and 10,000 samples
Interface: USB-cable, LAN
Display: 5" Capacitive Color Touchscreen
Languages: Chinese, English, French, German, Italian, Japanese, Russian, Spanish
Power supply: 12 V DC; max. 3 A
Weight: 7 kg
Weight: 15.5 lb
Operating temperature: 10 - 40 °C
Storing temperature: 0 - 60 °C
Operating temperature: 50 - 104 °F
Storing temperature: 32 - 140 °F
Relative humidity: Up to 85% at 35 °C (95 °F), non-condensing
Dimensions: L x W x H: 39 x 26 x 19 cm
Dimensions: L x W x H: 15.35 x 10.2 x 7.5 in
