Width: 6 mm
Height: 9.5 mm
Length: 14.3 mm
Fall Time: 18 us
Rise Time: 18 us
Output Type: NPN Phototransistor
Unit Weight: 260 mg
Configuration: 1 Channel
Isolation Voltage: 5000 Vrms
Number of Channels: 1 Channel
If - Forward Current: 50 mA
Vf - Forward Voltage: 1.4 V
Vr - Reverse Voltage: 6 V
Current Transfer Ratio: 260 %
Pd - Power Dissipation: 200 mW
Maximum Collector Current: 50 mA
Maximum Operating Temperature: + 100 C
Minimum Operating Temperature: - 30 C
Maximum Collector Emitter Voltage: 35 V
Maximum Collector Emitter Saturation Voltage: 200 mV
