Length: 3.2 mm
Diameter: 4.5 mm
Core Type: Wirewound
Q Minimum: 50
Shielding: Unshielded
Tolerance: 10 %
Inductance: 120 uH
Application: Power
Termination: Standard
Unit Weight: 179 mg
Core Material: Ferrite
Mounting Style: PCB Mount
Test Frequency: 796 kHz
Termination Style: SMD/SMT
Maximum DC Current: 320 mA
Saturation Current: 440 mA
Maximum DC Resistance: 2.2 Ohms
Self Resonant Frequency: 8 MHz
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
