Life: 10000 Cycle
Taper: Linear
Features: Carbon Element, Insulated Shaft
IP Rating: IP40
Tolerance: 20 %
Resistance: 1 MOhms
Shaft Type: Knurled / Serrated
Orientation: Horizontal
Switch Type: No Switch
Unit Weight: 2.100 g
With Switch: No Switch
Element Type: Carbon
Power Rating: 50 mW (1/20 W)
Shaft Length: 20 mm
Mounting Style: PCB Mount
Shaft Diameter: 6 mm
Voltage Rating: 50 VAC, 20 VDC
Number of Gangs: 1 Gang
Number of Turns: 1 Turn
Number of Detents: Without Detent
Termination Style: PC Pin
Maximum Operating Temperature: + 50 C
Minimum Operating Temperature: - 10 C
