BKPRECISION MDL302 Modular Programmable DC Electronic Load (0-80V, 0-45A, 300W)

Input Voltage: 0-80V

Input Current: Low: 0-4.5 A; High: 0-45 A

Input Power: 300 W / 300 W

Channel: 2

Minimum operating voltage: Low: 0.14 V at 4.5 A; high: 1.4 V at 45 A

Mode Regulation: CV, CC, CR, CW

Measurement: A, V, W

Over-Current/Over-Voltage/Over-Power/Over Temperature Protection

General (typical)

Short Circuit:

Current (CC): Low: 5A; High: 50A

Voltage (CV): 0 V

Resistance (CR): 30 mΩ

Input Terminal Impedance: 300 kΩ

Safety: EN61010-1:2001, EU Low Voltage Directive 2006/95/EC

Dimensions: 3.2” x 7.2” x 22.6” (82 x 183 x 573 mm)

Weight: 11 lbs (5 kg)
