Input Ratings
Input Voltage : 0 to 800 V
Input Current: 0 to 75 A
Input Power: 3000W
Minimum Operating Voltage: 2.0 V
CV Mode
Range: Low: 0 to 80 V; High: 0 to 800 V
Programming Readback / Accuracy: ±(0.05% + 0.05% FS)(1)
CC Mode
Range: Low: 0 to 7.5 A; High: 0 to 75 A
Programming Readback / Accuracy: ±(0.05% + 0.05% FS)(1)
CR Mode
Range: Low: 0.03 Ω to 10.66 Ω; High: 10.66 Ω to 5000 Ω
Programming Accuracy (I > 10% of Range): 1% + 0.1% of full range
CW Mode
Range: Low: 0 to 300 W; High: 0 to 3000 W
Programming Accuracy: ±(0.2% + 1% FS)
Transient Mode (CC Mode)
T1 & T2: 100 µs to 10 s
Accuracy: 5 µs ± 100 ppm
Slew Rate (2): Low/High: 0.025 to 1500 A/ms
External Programming
VMON Accuracy: 0.1% + 0.1% FS
IMON Accuracy: 0.1% + 0.1% FS
Input Impedance: 210 kΩ ± 5%
Voltage (OVP)
Range: 0.525 V to 840 V
Accuracy : 0.2% + 1.05 V
Current (OCP)
Range: 0.049 A to 78.75 A
Accuracy : 0.2% + 0.098 A
Under Voltage Lockout (UVL)
Range: 0.6 V to 800 V
Accuracy : 2.5% + 1 V
General
AC Input: 100 VAC to 240 VAC ± 10%, 47 to 63 Hz
Operating Temperature: 41 °F to 104 °F (5 °C to 40 °C)
Dimensions (H x W x D): 5.24” x 16.87” x 26.18” (133 x 428.4 x 665 mm)
Weight: 48.5 lbs (22 kg)
Standard Accessories: Power cord, removable input protection cover, and certificate of calibration
Regulatory Compliance
Safety: Low Voltage Directive (LVD) 2014/35/EU, EN61010-1:2010+A1, cTUVus certification mark(3) fulfills US (UL 61010-1:2012) and Canadian (CAN/CSA-C22.2 NO. 61010-1-12) safety standards
Electromagnetic Compatibility: EMC Directive 2014/30/EU, EN61326-1:2013
