Input Ratings
Input Voltage : 0 to 600 V
Input Current: 0 to 300 A
Input Power: 6000 W
Minimum Operating Voltage: 3.5 V
CV Mode
Range: Low: 0 to 60 V; High: 0 to 600 V
Programming Readback / Accuracy: ±(0.05% + 0.05% FS)(1)
CC Mode
Range: Low: 0 to 30 A; High: 0 to 300 A
Programming Readback / Accuracy: ±(0.05% + 0.05% FS)(1)
CR Mode
Range: Low: 0.015 Ω to 2 Ω; High: 2 Ω to 1600 Ω
Programming Accuracy (I > 10% of Range): 1% + 0.1% of full range
CW Mode
Range: Low: 0 to 600 W; High: 0 to 6000 W
Programming Accuracy: ±(0.2% + 1% FS)
Transient Mode (CC Mode)
T1 & T2: 100 µs to 10 s
Accuracy: 5 µs ± 100 ppm
Slew Rate (2): Low/High: 0.1 to 6000 A/ms
External Programming
VMON Accuracy: 0.1% + 0.1% FS
IMON Accuracy: 0.1% + 0.1% FS
Input Impedance: 210 kΩ ± 5%
Voltage (OVP)
Range: 0.394 V to 630 V
Accuracy : 0.2% + 0.788 V
Current (OCP)
Range: 0.197 A to 315 A
Accuracy : 0.2% + 0.394 A
Under Voltage Lockout (UVL)
Range: 0.45 V to 600 V
Accuracy : 2.5% + 0.75 V
General
AC Input: 100 VAC to 240 VAC ± 10%, 47 to 63 Hz
Operating Temperature: 41 °F to 104 °F (5 °C to 40 °C)
Dimensions (H x W x D): 8.74” x 16.87” x 24.21” (222 x 428.4 x 615 mm)
Weight: 73.8 lbs (33.5 kg)
Standard Accessories: Power cord, removable input protection cover, and certificate of calibration
Regulatory Compliance
Safety: Low Voltage Directive (LVD) 2014/35/EU, EN61010-1:2010+A1, cTUVus certification mark(3) fulfills US (UL 61010-1:2012) and Canadian (CAN/CSA-C22.2 NO. 61010-1-12) safety standards
Electromagnetic Compatibility: EMC Directive 2014/30/EU, EN61326-1:2013
