BKPRECISION HMR500108 ATE System DC Power Supplies (18 kW ; 500 V ; 108 A)

Output Power : 18 kW

Output Characteristics:

Max Output Voltage : 500 V

Max Output Current : 108 A

Load Regulation:

Voltage : 250 mV

Current : 162 mA

Ripple and Noise (20 Hz to 20 MHz) : < 375 mVpp; < 75 mVrms

Rise Time at Full Load : < 30 ms

Fall Time No Load : < 5 s

Programming Accuracy:  ± 500 mV

Multi-range (autorange)  : ✔

Features:

Front Panel USB : ✔

Touchscreen Display : ✔

CV / CC / CP Priority : ✔

Internal Resistance Simulation : ✔

Parallel operation : 100 units max

Protection : OVP / OCP / OPP / OTP / key-lock / Optional reverse voltage protection unit

General:

Form Factor:  3U

Command Response Times : 3 ms

I/O Interfaces : Standard: LAN (LXI) and USB. Optional: User-installable GPIB and Analog

AC Input : Wide range (nominal): 200 to 415 VAC
