Output Rating:
Voltage: 0–30 V (Ch1 & Ch2), 0-5 V (Ch3)
Current: 0-3 A (Ch1, Ch2), 0-3 A (Ch3)
Power: 195 W
Load Regulation: ≤ 0.01% + 3 mV; ≤ 0.1% + 3 mA
Line Regulation: ≤ 0.01% + 3 mV; ≤ 0.1% + 3 mA
Ripple and Noise: ≤ 1mVrms; ≤ 3mArms
Programming Resolution: 1 mV; 1 mA
Readback Resolution: 1 mV; 1 mA
General:
Memory: 4 memory groups with 9 locations in each group
Timer: 0.1 to 99999.9 seconds
Remote Interface: USB (USBTMC-compliant) and RS232
AC Input: 110/220 VAC (±10 %), 47 Hz to 63 Hz
Operating Temperature: 32°F to 104°F (0°C to 40°C), relative humidity up to 80%
Storage Temperature: -4°F to 158°F (-20°C to 70°C)
Dimensions (W x H x D): 8.45" x 3.47" x 13.96" (214.5 x 88.2 x 354.6 mm)
Weight: 16.98 lbs. (7.7 kg)
Standard Accessories: Power cord, instruction manual, and certificate of calibration
Optional Accessories: IT-E151 rack mount kit
