Without GPIB
Output Rating:
Voltage: 0~80 V
Current: 0~60 A
Power: 1200 W
Load Regulation: 0.01 % + 5 mV; 0.1 % + 10 mA
Line Regulation: 0.02 % + 1 mV; 0.02 % + 1 mA
Ripple (20 Hz - 20 MHz): ≤ 60 mVpp; 100 mArms
Programming Resolution: 1 mV; 1 mA
Readback Resolution: 1 mV; 1 mA
General:
Efficiency: 73% (120 VAC); 75% (220 VAC)
Power Factor (full load): 0.99
Standard Interface: USB, GPIB (optional), RS232, RS485
AC Input: 115/230 VAC ± 10 %, 47 Hz to 63 Hz
Input Current (nominal): 13.8 A (120 VAC); 7.3A (220 VAC)
Operating Temperature: 32 ºF to 104 ºF (0 ºC to 40 ºC)
Storage Temperature: -4 ºF to 158 ºF (-20 ºC to 70 ºC)
Safety: EN61010-1:2001, EU Low Voltage Directive 2006/95/EC
Dimensions (W x H x D): 16.32” x 1.75” x 19.02” (414.5 x 44.5 x 483.2 mm)
Included Accessories: User manual, AC power cord (9115/B, 9115/B-AT, and 9116/B only), unterminated AC power cord with input connector (9117 only), rackmount kit, certificate of calibration
