Input ratings
- Input voltage: 0 – 500 V
- Input current: Low: 0 –6 A; High: 0 –60 A
- Input power: 1200 W
- Minimum operating voltage: Low: 0.36 V at 6 A; High: 3.6 V at 60 A
CV mode:
- Range: Low: 0 – 50 V; High: 0 – 500 V- Resolution: Low: 1 mV; High: 10 mV
- Accuracy: Low: ±(0.025% + 0.05% FS); High: ±(0.025% + 0.05% FS)
CC mode
- Range: Low: 0 – 6 A; High: 0 – 60 A
- Resolution: Low: 0.1 mA; High: 1 mA
- Accuracy: Low:±(0.05%+ 0.05% FS); High: ±(0.05%+ 0.05% FS)
CR mode
- Range: Low: 0.01 Ω – 10 Ω; High: 10 Ω - 7.5 kΩ
- Resolution: 16 bit
- Accuracy: Low: 0.01%+0.08 S; High: 0.01%+0.0008 S
CW mode
- Range: 1200 W
- Resolution: 100 mW
- Accuracy: 0.2% + 0.2% FS
Transient mode (CC mode)
- T1 & T2: 20 µs to 3600 s/Resolution: 10 µs
- Accuracy: 5 µs ± 100 ppm
- Slew rate: Low: 0.0001-0.1 A/µs; High: 0.001-1 A/µs
Readback voltage
- Range: Low: 0 – 50 V; High: 0 – 500 V
- Resolution: Low: 1 mV; High: 10 mV
- Accuracy: ±(0.025% + 0.025% FS)
Readback current:
- Range: Low: 0 – 6 A; High: 0 – 60 A
- Resolution: Low: 0.1 mA; High: 1 mA
- Accuracy: ±(0.05% + 0.05% FS)
Readback power:
- Range: 1200 W
- Resolution: 10 mW
- Accuracy: ±(0.2% + 0.2% FS)
Protection range (typical)
- OPP: 1250 W
- OCP: Low: 6.6 A; High: 66 A
- OVP: 530 V
- OTP: 185 ºF (85 °C)
Short circuit (typical):
- Current: (CC): Low: 6.6 A; High: 66 A
- Voltage: 0V
- Resistance: 60 mΩ
Input terminal impedance (typical): 1 MΩ
AC input: 110 V/220 V ±10%, 50/60 Hz
Temperature
- Operating: 32 °F to 104 °F (0 °C to 40 °C)
- Storage: 14 °F to 140 °F (-10 °C to 60 °C)
Humidity Indoor: use, ≤ 95 %
Dimensions: 17.3” x 5.3” x 22.5” (439 x 133.3 x 580 mm)
Weight: 54 lbs (24.6 kg)
Standard accessories: User Manual; Power cord, certificate of calibration & test report
Optional accessories: TLPWR1 high current test leads
