Without GPIB
Input voltage: 0 – 500 V
Input current: 0~3A; 0~30A
Input power: 750W
Mode: CV mode, CC mode, CR mode, CW mode
Readback Voltage: 0~18; 0~120V
Readback Current: 0~3A; 0~30A
Readback Power: 750W
General (typical):
Input terminal impedance: 1 MΩ
AC input: 110 V/220 V ±10%, 50/60 Hz
Operating temperature: 32 ºF to 104 ºF (0 °C to 40 °C)
Storage temperature: 14 ºF to 140 ºF (-10 °C to 60 °C)
Humidity: Indoor use, ≤ 95%
Safety: EN61010-1:2001, EU Low Voltage Directive 2006/95/EC
Dimensions (W x H x D): 17.3” x 5.3” x 22.5” (439 x 133.3 x 580 mm)
Weight: 54 lbs (24.6 kg)
Standard accessories: User manual, power cord, certificate of calibration
Optional accessories: TLPWR1 high current test leads
