BK Precision 2552 Digital Storage Oscilloscope (70Mhz, 2CH, 2 GSa/s)

Manuafacturer: BK PRECISION
Model : 2552
Original: China
Warranty : 12 month

Bandwidth: 70 MHz
Real Time Sampling Rate: 2 GSa/s (half-channel interleaved), 1 GSa/s (per channel)
Channels: 2
Max Memory Depth: 24 kpts (half-channel interleaved)(1)(2), 12 kpts (per channel)
Vertical Resolution: 8 bit
Vertical Sensitivity: 2 mV/div -10 V/div (1-2-5 order)
Horizontal Scan Range: 5 ns/div – 50 s/div
Maximum Input Voltage: 400 V (DC+AC pk-pk, 1 MΩ input impedance, X10)
I/O Interface: USB, LAN
Trigger: Edge, Pulse Width, Video*, Slope, Alternative
Math Operation: Add, Subtract, Multiply, Divide, FFT
FFT: Hanning, Hamming, Blackman, Rectangular
Measure: Vpp, Vmax, Vmin, Vamp, Vtop, Vbase, Vavg, Mean, Crms, Vrms, ROV, FOV, RPRE, FPRE, FREQ, Period, Rise Time, Fall Time, BWid, + Wid, - Wid, + Duty, - Duty, Phase, FRR, FRF, FFR, FFF, LRR, LRF, LFR, LFF
Display: 7 in. Color TFT, 480 x 234 resolution, 64K color
Power Requirements: 100-240 VAC
Dimensions: 358 x 156 x 118 mm
Weight: 4.3kg
Supplied Accessories: User manual, passive probes (one per channel), power cord, certificate of calibration, USB (Type A to B) communication cable
