Power Rating: 300 W
Connector: N
VSWR and Frequency Range:
1.10:1 from DC to 1 GHz
1.25:1 from 1 to 2.4 GHz
Coolant Method: Dry, Convection Cooled
Impedance: 50 Ohms
Temperature: -40 to 40 °C (-40 to 104 °F)
PIM: -110 dBc Min.
Humidity: 95% non-condensing
Standard Attenuation Values: 20dB
Dimensions: 7.3” x 5.4” x 10.9”/ 186 x 138 x 277 mm
Weight: 12.0 lbs./ 5.5 kg
Finish: Black Anodized Aluminum
