Frequency:
Range: 1~6000 MHz
Resolution: 1kHz
Accuracy: ±2.5×10-6 @25 °C
Output Power: -10 dBm, typical
Measurement: Speed: 1 ms / data point; Points: 51 to 3201
Measure Bandwidth: 100 Hz to 30 kHz
Temperature Stability: 0.01 dB/°F (0.02 dB/°C)
Return Loss Measurement Range: 0 dB to -60 dB
Resolution: 0.01 dB
VSWR Measurement Range: 1.0 to 65.0
Cable Loss Measurement Range: 0 dB to 30 dB
DTF Range: 0 to 5000 ft. (0 to 1500 m)
Maximum Input Voltage: 50V
Connectors: USB Type-C, USB 3.0
Test Port Connector: N-type, Female 50 Ohms
Temperature Operating: 14 to 131 °F (–10 to +55 °C)
Temperature Storage: -40 to 176 °F (-40 to +80 °C)
Display: 5.5 in, 720 p
Languages: English, Chinese, Spanish
Battery Type: Lithium-ion rechargeable
Operating Time: 10 hours typical
Charging Time: 5 hours typical
Dimensions: 7.7 in x 3.6 in x 2.4 in/ (195 mm x 90 mm x 60 mm)
Weight: 1.98 lbs. (0.9 (kg)
