Bevs BEVS 3228N Intelligent Robotic Coating Station (80-150mm)

Robot

- Horizontal moving

Stroke: 1000mm

Pre-allocation time: 4s

Max Speed : 500mm/s

- Vertical drop of fixture

Stroke: 300mm

Pre-allocation time: 3s

Max Speed : 300mm/s

- Vertical rise of fixture

Stroke: 300mm

Pre-allocation time: 2s

Max Speed : 300mm/s

- clamp

Stroke: /

Pre-allocation time: 2s

Max Speed : 0.6mm/s

- Maximum acceleration

Stroke: /

Pre-allocation time: 5m/s²

Max Speed: /

- Clamping fixture range

Stroke: /

Pre-allocation time: Single side 80-150mm

Max Speed : /

- Maximum weight of sample

Stroke: /

Pre-allocation time: 2kg

Max Speed : /

Drawdown info:

Continuous coating drawdown speed: 40s/pcs

Duration of working: 7 x 24h

Compatible paints: 10 kinds of paints

Maximum storage standard panels: 100pcs

Maximum storage panel bracket: 5pcs

Maximum storage coated panels: 5pcs

Standard Substrate size (maximum): 150x70mm

Test platform: Standard cement slab

Coating tool: Bar Coater

Station info:

Weight: 350kg

Voltage: 220V/50Hz

Power: 2.5 KW

Air pressure: 0.5Mpa (no oil and no water)

Workstation size: 1400 X 1240 X 2030mm (L X W X H )

Environment request:

Temperature: +15-35°C

Humidity: 20-80% RH (non- condensation)

Introduction

With the development of Industry 4.0 and improve the competitiveness of products, accelerating the speed of research and development, BEVS has developed the first small intelligent robot coating station in the paints and coatings industry. BEVS 3228N Intelligent Robotic Coating Station is an intelligent small workstation which integrates intelligent instrument, robot, automatic control system and testing material. The robot automatically completes the loading and unloading, realizes the rapid automatic drawdown film, greatly improves the reproducibility and efficiency of the coating, and obtains the uniform coating film in physical properties, appearance and chemical properties. All kinds of instability caused by the factors such as velocity, pressure and direction in the coating process were eliminated, and a high precision testing result was provided for testing rheological properties, wear resistance and hiding power of the material and so on.

Features

Real time Data encrypted transmission

Testing automatically

Free combination of instruments and equipment

System work by remote command

Data, analysis, and result report can be obtained at anytime and anywhere

Sharing with intelligent and automated production workshop

Shorten the R & D and testing cycle time.

High efficiency and greatly reduced R & D cost

Data saving and output

Fast automatic drawdown with different coatings

Environmental protection, energy-saving and confined space

Order Info

BEVS 3228N Intelligent Robotic Coating Station
