Bel Signal Transformer F1C1-322510-1R5M High Power Shielded SMD Inductor FIXED INDUCTOR 1.5 uH 3.6A 42 MOHM

Width: 2.5 mm

Height: 1 mm

Length: 3.2 mm

Core Type: Toroidal

Shielding: Shielded

Tolerance: 20 %

Inductance: 1.5 uH

Application: DC to DC Converters, Cellular Phones

Termination: Standard

Core Material: Iron

Mounting Style: PCB Mount

Test Frequency: 1 MHz

Termination Style: SMD/SMT

Maximum DC Current: 3.6 A

Saturation Current: 5 A

Maximum DC Resistance: 42 mOhms

Maximum Operating Temperature: + 125 C

Minimum Operating Temperature: - 55 C
