Mode: CV, CC, CP, CR
Display: 5-inch TFT Color LED
Max.Input voltage: 500V
Max.Input current: 60A (Extend to 120A)
Max.Input power: 3000W
Basic accuracy of voltage: 0.05%+0.03%FS
Basic accuracy of current: 0.05%+0.05%FS
Min. resolution:
- Voltage: 0.1mV
- Current: 0.1mA
List test function: CV, CC, CP, CR, Short, Open
Battery test function
- Max. capacity: 999A/H
- Discharge time: 1~60000sec with discharge curve
Dynamic test function: Frequency range 0.1Hz-25KHz
Remote test function: Available
Standard RS232C: Available
USB device: Available
USB flash storage: Available
Protective method: Over voltage, current, power, temperature; Reversely connection of polarity
W*H*D: 430mm*200mm*510mm
Power: 198-242VAC 99V-121VAC 47.5-63Hz
