Rated value:
- Input voltage: 0~500V
- Input current: 0.1mA~30A
- Input power: 300W
Range/ Accuracy/ Resolusion
Load accuracy: 0-9.9999V/ ±(0.05%+0.03%FS)/ 0.1mV
10V-99.999V/ ±(0.05%+0.03%FS)/ 1 mV
100V-150V/500V/ ±(0.05%+0.03%FS)/ 10mV
0-9.9999A/ ±(0.05%+0.05%FS)/ 0.1mA
10-30A/60A/ ±(0.05%+0.05%FS)/ 1 mA
CV mode: 1.5V-36V/ ±(0.05%+0.03%FS)/ 0.1mV/1mV
1.5V-150V/500V/ ±(0.05%+0.03%FS)/ 10 mV
CC mode: 0-3A/6A/ ±(0.05%+0.05%FS)/ 0.1mA
0-30A/60A/ ±(0.05%+0.05%FS)/ 1mA
CR mode: 0.05Ω-5Ω/ ±(0.2%+0.2%FS)/ 0.0001Ω
0.5Ω-50Ω/ ±(0.1%+0.1%FS)/ 0.001Ω
5Ω-500Ω/ ±(0.1%+0.1%FS)/ 0.01Ω
500Ω-5KΩ/ ±(1%+1%FS)/ 0.1Ω
CP mode: 0-50W/ ±(0.1%+0.1%FS)/ mW
0-150W/ ±(0.1%+0.1%FS)/ 10mW
0-300W/ ±(0.1%+0.1%FS)/ 0.1W
Battery test function
- Input voltage: 2-150V/500V
- Max measurement capacity: 9999AH
- Timer range =1 ~ 4294967295sec (>7 days)
Dynamic test mode:
- Min plus width: 0.1ms
- Max plus width: 999s
- Rising/Falling edge resolution: 0.1ms
- Max Rising/Falling edge time: 6s
List test mode: Rated Voltage, Rated Current, Rated Power, Rated Resistance, Short, Open
Programming test mode
- Sweep type: Current, Voltage, Power
- Critical conditions: V-threshold, DV, Drop
