Rated value:
- Input voltage: 0~120V
- Input current: 1mA~60A
- Input power: 150W
Range/ Accuracy/ Resolution
- Load accuracy:
0-9.9999V/ ±(0.05%+0.03%FS)/ 0.1mV
10.000V-99.999V/ ±(0.05%+0.03%FS)/ 1mV
100.00V-500.00V/ ±(0.05%+0.03%FS)/ 10mV
0-3A/ ±(0.05%+0.05%FS)/ 0.1 mA
0-30A/60A/ ±(0.05%+0.05%FS)/ 1 mA
- Rated voltage mode:
1.5V-18V/ ±(0.05%+0.03%FS)/ 1mV
1.5V-150V/500V/ ±(0.05%+0.03%FS)/ 10mV
- Rated current mode:
0-3A/ ±(0.05%+0.05%FS)/ 0.1mA
0-30A/60A/ ±(0.05%+0.05%FS)/ 1mA
- Fixed resistance mode (When the input voltage and current value is greater than 10% FS)
0.05Ω-5Ω/ ±(0.2%+0.2%FS)/ 0.001Ω
0.5Ω-50Ω/ ±(0.1%+0.1%FS)/ 0.01Ω
5Ω-500Ω/ ±(0.1%+0.1%FS)/ 0.1Ω
500Ω-5KΩ/ ±(1%+1%FS)/ 1Ω
- Fixed power mode (When the input voltage and current value is greater than 10% FS)
0-50W/ ±(0.1%+0.1%FS)/ 1mW
0-150W/ ±(0.1%+0.1%FS)/ 10mW
0-300W/ ±(0.1%+0.1%FS)/ 0.1W
- Voltage measurement accuracy
0-9.9999V/ ±(0.05%+0.03%FS)/ 0.1mV
10.000-99.999V/ ±(0.05%+0.03%FS)/ 1mV
100.00-150.00V/500.00V/ ±(0.05%+0.03%FS)/ 10mV
- Current measurement accuracy
0-9.9999A/ ±(0.05%+0.05%FS)/ 0.1mA
10.000-30.000/60.000A/ ±(0.05%+0.05%FS)/ 1mA
Battery test function
- Input= 0.8-150V/500V; Max measurement capacity= 999A/H
- Resolution=0.1mA; Timer range=1~60000sec
Dynamic test mode: T1&T2(A or B test time): 0.025mS-999S; Error<2.5% + 0.01mS
Protection range: >specified condition 5%
Impedance in the input terminal: ≥200KΩ
Dimensions: W*H*D 215mm*88mm*335mm
Weight: 5.5Kg
