Beich CH9710C Economical Programmable DC Electronic Load (0~360V; 0.1mA~30A; 300W; High brightness VFD)

Rated value:

- Input voltage: 0~360V

- Input current: 0.1mA~30A

- Input power: 300W

Display mode: High brightness VFD

Range/ Accuracy/ Resolving Power

Load accuracy: 0-36V/ ±(0.05%+0.03%FS)/ 1mV

0-360V/ ±(0.05%+0.03%FS)/ 10mV

0-3A/ ±(0.05%+0.05%FS)/ 0.1mA

0-30A/ ±(0.05%+0.05%FS)/ 1mA

Fixed voltage mode: 1.5V-36V/ ±(0.05%+0.03%FS)/ 1mV

1.5V-360V/ ±(0.05%+0.03%FS)/ 10mV

Fixed current mode: 0-3A/ ±(0.05%+0.03%FS)/ 0.1mA

0-30A/ ±(0.05%+0.03%FS)/ 1mA

Fixed resistance mode: 0.1Ω-10Ω/ ±(0.2%+0.2%FS)/ 0.001Ω

10Ω-99Ω/ ±(0.1%+0.1%FS)/ 0.01Ω

100Ω-999Ω/ ±(0.1%+0.1%FS)/ 0.1Ω

1KΩ-4KΩ/ ±(1%+1%FS)/ 1Ω

Fixed power mode: 0-10W/ ±(0.1%+0.1%FS)/ 1mW

10-100W/ ±(0.1%+0.1%FS)/ 10mW

100-300W/ ±(0.1%+0.1%FS)/ 0.1W

Current measurements: 0-3A/ ±(0.05%+0.05%FS)/ 0.1mA

0-15A/30A/ ±(0.05%+0.05%FS)/ 1mA

Voltage measurements: 1.5V-36V/ ±(0.05%+0.03%FS)/ 0.1mV

1.5V-360V/ ±(0.05%+0.03%FS)/ 1mV

Battery test function

- Input voltage: 0.8-360V

- Maximum capacity: 999A/H

- Resolving power: 0.1mA

- Discharge time: 1~60000sec

Dynamic test mode:

- T1&T2(A or B Value Test Time): 1mS-999S

- Error<2.5%+0.1mS

Protection scope: >Rated condition 5%

Input impedance: ≥200KΩ

Outline size: W*H*D 215mm*88mm*335mm

Weight: About 6.5Kg
