Resolution (H x V Pixels): 4112 x 2176 (full resolution) / 4096 x 2168 (default resolution) / You can change the resolution by changing the image ROI.
Resolution: 8.9 MP
Sensor Type: Sony IMX267LQR / Progressive scan CMOS / Global shutter
Sensor Format: 1 inch
Effective Sensor Diagonal: 16.1 mm
Pixel Size (H x V): 3.45 x 3.45 μm
Frame Rate (at Default Settings): 13.1 fps
Mono / Color: Color
Image Data Interface: Fast Ethernet (100 Mbit/s) Gigabit Ethernet (1000 Mbit/s)
Synchronization: Via hardware trigger / Via software trigger / Via free run
Exposure Time Control: Via hardware trigger / Programmable via the camera API
Camera Power Requirements: ≈3.3 W (typical) when using Power over Ethernet / ≈2.8 W (typical) @ 12–24 VDC when supplied via I/O connector
I/O Lines: 1 opto-coupled input line / 1 opto-coupled output line / 1 general purpose I/O (GPIO) line
Lens Mount: C-mount
Size (L x W x H): 50.0 x 40 x 30 mm (without lens mount or connectors) / 61.8 x 40 x 30 mm (with lens mount and connectors)
Weight: <90 g
Conformity: CE (includes RoHS), EAC, UL Listed, FCC, GenICam, GigE Vision, IP30, IEEE 802.3af (PoE), REACH, KC
Software: Basler pylon Camera Software Suite (version 4.0 or higher) Available for Windows, Linux x86, Linux ARM, macOS, and Android
Product Line: ace L
