Banner Engineering SMA30PELQDB Photoelectric Sensors SM30 Series: Emitter - Frequency B PBT Polyester; Range: 150 m; Input: 10-30 V dc /12-240 V ac; Output: Not Applicable; 3-pin Mini Integral QD

Height: 114 mm

IP Rating: IP67

Unit Weight: 152.407 g

Light Source: Infrared

Amplifier Type: Photoelectric

Sensing Method: Opposed Emitter

Sensing Distance: 150 m

Connection Method: 3-Pin Mini

Supply Voltage - Max: 240 VAC/30 VDC

Supply Voltage - Min: 12 VAC/10 VDC

Operating Supply Voltage: 12 VAC to 240 VDC, 10 VDC to 30 VDC

Maximum Operating Temperature: + 70 C

Minimum Operating Temperature: - 40 C
