Range: 5 - 3000HV
Weight: 100kg
Dimension: 580 x 260 x 730mm
Test Force: 9.807,49.04, 98.07, 196.1, 294.2, 490.4 N 1, 5, 10, 20, 30, 50 kgf
Test Height: 180mm
Power Supply: AC220V, 50Hz / 60 Hz
Throat Depth: 125mm
Magnification: 100X, 200X
Load Dwell Time: 5 - 60 seconds
Min. Testing Unit: 0.125μm
5.6" LCD touch screen.
Auto hardness conversion to others scales, no need to check table and improve working efficiency.
Dynamic display of pressure head during loading and unloading process, real-time test status.
Test force, indentation lenght, holding time, measurement frequency, etc. display on the screen.
Concave and convex surfaces hardness value auto correction.
Test result synchronized to database and export.
Support USB and RS232 interface.
Precision conforms to standard ISO 6507 and ASTM E92.
