Artesyn AEE00B24-M Isolated 10W 18-36Vin Single 12V@0.835A

Width: 25.4 mm (1 in)

Height: 10.2 mm (0.402 in)

Length: 50.8 mm (2 in)

Industry: Medical

Unit Weight: 30 g

Output Power: 10 W

Input Voltage: 18 V to 36 V

Mounting Style: Through Hole

Isolation Voltage: 4.2 kV

Number of Outputs: 1 Output

Input Voltage - Max: 36 V

Input Voltage - Min: 18 V

Input Voltage, Nominal: 24 V

Output Current-Channel 1: 835 mA

Output Voltage-Channel 1: 12 V

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 40 C
