Input voltage: DC24V (RJ45 interface)/Three in one socket (220VAC 50/60Hz)
Input current: ＜0.25A AC
Output voltage: DC±4.5KV - ±5.5KV
Power: ＜55W
Ion emission: DC
Emitter electrode: Tungsten alloy
Discharge range: 750x1050mm
Discharge speed: ≤2.5s (450mm from the air outlet)
Ion balance: ≤/±15V/
Alarm indication:
Power on/clean operation-blue light flashes
Normal work-green light (always in monitoring state)
Fan alarm - red light is always on
High voltage abnormally-red light flashes
Blue light flashes during infrared debugging
Air volume: ≤93CFMx4
Noise: Single air outlet ≤45dbA (1000mm away from the air outlet)
Ozone thickness: ≤0.05ppm (1500mm away from the air outlet)
Communication method: RS485
Operating temperature: 0-50℃
Working humidity: ＜70%RH
Dimensions: 1053x154x114mm (LxWxH)
