Measuring Range
Viscosity: 0.2 mm²/s to 30,000 mm²/s
Density: 0 g/cm³ to 3 g/cm³
Temperature: +15 °C to +100 °C
Precision
Viscosity repeatability and reproducibility: 0.1 % and 0.35 %
Density repeatability and reproducibility: 0.0002 g/cm³ (0.00005 g/cm² with ASTM D4052 option) and 0.0005 g/cm³ (0.0001 g/cm² with ASTM D4052 option)
Cloud/freeze point repeatability and reproducibility: -
Temperature repeatability: 0.005 °C
Temperature reproducibility: 0.03 °C from +15 °C to +100 °C
Performance
Sample volume min. / typical: 1.5 mL / 5 mL
Solvent volume min. / typical: 1.5 mL / 6 mL
Max. sample throughput: 33 samples per hour
Data memory: 1,000 measurement results
HID (Human Interface Device): 10.4" touchscreen, optional keyboard, mouse, and 2D bar code reader
Interfaces: 4 x USB (2.0 full speed), 1 x Ethernet (100 Mbit), 1 x CAN bus, 1 x RS-232, 1 x VGA
Power supply: AC 100 V to 240 V, 50 Hz to 60 Hz, 250 VA max.
Ambient conditions: 15 °C to 35 °C, max. 80 % r.h. non-condensing
Net weight : 15.9 kg
Dimensions (W x D x H): 33 cm x 51 cm x 23.1 cm
