Max. load [N]: Fine range: 100; Large range: 200
Resolution [mN]: Fine range: 0.1; Large range: 0.2
Noise floor [rms] [μN]*: Fine range: 1000
Penetration depth (only RST 300)
Max. depth [μm]: Fine range: 100; Large range: 1000
Depth resolution [nm]: Fine range: 0.05; Large range: 0.5
Noise floor [rms] [nm]*: Fine range: 2.5
Friction load
Max. friction [N]: Fine range: 100; Large range: 200
Friction resolution [mN]: Fine range: 0.1; Large range: 0.2
Acoustic emission sensor:
Central frequency: 150 kHz
Dynamic range: 65 dBae
Maximum amplification: 200,000 x
Scratching speed:
From 0.4 mm/min to 600 mm/min
Scratch tables:
Scratch length: up to 70 mm
Inline scratch inspection: up to 30 mm
Scratch speed: 0.4 mm/min to 600 mm/min
