Standard methods: ASTM D8206
Sample volume: Typically 5 mL, or 4 g
Test chamber material: Stainless steel
Application range: Up to 180 °C
Re-cooling: Fan and Peltier, approximately 10 min
Pressure range: Up to 1800 kPa during measurement, filling pressure up to 700 kPa
Internal memory: 100 test results, or endless mode setting
Safety: Screw cap cover, safety and insulation hood, over-temperature and over-pressure shut-off
Display: Live values for pressure, temperature, and pressure/time curve
Interface:
1 × USB at the front/right side
1 × USB at the back of the instrument
1 × LAN
Power supply: AC 220 V - 240 V, 50/60 Hz AC 100 V - 120 V, 50/60 Hz
Airborne noise emission: <57 dB (A)
Dimensions: Approx. 200 mm × 400 mm × 250 mm (W × D × H)
Weight: <9 kg
