Measuring range
Temperature: -50 °C to +180 °C (-58 °F to 356 °F)
Resistance: 80 Ω to 175 Ω
Resolution
Temperature: 1 mK
Resistance: 0.4 mΩ
Measurement uncertainty**
Temperature: < 10 mK
Resistance: < 4 mΩ
General information
Temperature sensor: Pt 100 (EN 60751)
Measuring current: 1 mADC
Internal reference resistor: 400 Ω (Vishay Precision Group, VHP 101)
Number of sensor inputs: 1
Sensor connection: 4 wire, soldered
Measuring time: 1 second (for one channel)
Data outputs: LAN (PoE, 10 Mbit)
Ambient operating temperature: 0 °C to 35 °C (for highest accuracy 20 °C to 25 °C recommended)
Power supply: 4× AA batteries or Power over Ethernet (PoE)
Dimensions (L × W × H): 200 mm × 100 mm × 35 mm (7.9 in × 3.9 in × 1.4 in)
Weight: approx. 500 g (1.1 lbs)
